| Machine No. | TON | Modus | Servo Clamping Force | Surroundings | Manufacturer | Country of manufacturer | Force | Column distance (mm) | Max die opening (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 101 | 50 | Horizontal | Oil hydraulic | Thermostatic air conditioning | VICTOR 台中精機 | TW | Monochrome | 310*310 | 270 |
| 102 | 50 | Horizontal | Oil hydraulic | Thermostatic air conditioning | VICTOR
台中精機 | TW | Monochrome | 300*300 | 270 |
| 103 | 100 | Horizontal | Oil hydraulic | Thermostatic air conditioning | VICTOR
台中精機 | TW | Monochrome | 410*410 | 360 |
| 104 | 85 | Vertical | Oil hydraulic | Thermostatic air conditioning | MUILTPLAS 百塑 | TW | Monochrome, duplex turntable | 500*335 | 450 |
| 105 | 180 | Horizontal | Oil hydraulic | Thermostatic air conditioning | OMC超群 | TW | Monochrome | 470*470 | 490 |
| 106 | 150 | Horizontal | Oil hydraulic | Thermostatic air conditioning | ASIAN PLASTIC 震雄 | TW | Monochrome | 450*470 | 400 |
| 107 | 85 | Vertical | Oil hydraulic | Thermostatic air conditioning | MUILTPLAS 百塑 | TW | Monochrome, duplex turntable | 500*335 | 450 |
| 108 | 150 | Horizontal | Oil hydraulic | Thermostatic air conditioning | YEAR CHANCE義展 | TW | Monochrome | 470*470 | 420 |
| 109 | 150 | Horizontal | Oil hydraulic | Thermostatic air conditioning | YEAR CHANCE義展 | TW | Monochrome | 430*430 | 400 |
| 110 | 100 | Horizontal | Oil hydraulic | Thermostatic air conditioning | VICTOR
台中精機 | TW | Monochrome | 380*380 | 320 |
| 111 | 100 | Horizontal | Oil hydraulic | Thermostatic air conditioning | VICTOR
台中精機 | TW | Monochrome | 380*380 | 320 |
| 112 | 80 | Horizontal | Oil hydraulic | Thermostatic air conditioning | VICTOR
台中精機 | TW | Monochrome | 340*340 | 300 |
| 113 | 80 | Horizontal | Oil hydraulic | Thermostatic air conditioning | VICTOR
台中精機 | TW | Monochrome | 340*340 | 300 |
| Machine No. | TON | Modus | Servo Clamping Force | Surroundings | Manufacturer | Country of manufacturer | Force | Column distance (mm) | Max die opening (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 201 | 180 | Horizontal | Oil hydraulic | Clean room class 100,000 | VICTOR 台中精機 | TW | Monochrome | 310*310 | 270 |
| 202 | 150 | Horizontal | ALL-ELECTR | Clean room class 100,000 | FANUC 發那科 | JPN | Monochrome | 300*300 | 270 |
| 203 | 100 | Horizontal | ALL-ELECTR | Clean room class 100,000 | FANUC 發那科 | JPN | Monochrome | 410*410 | 360 |
| 204 | 150 | Vertical | ALL-ELECTR | Clean room class 100,000 | FANUC 發那科 | JPN | Monochrome, duplex turntable | 500*335 | 450 |
| 205 | 150 | Horizontal | ALL-ELECTR | Clean room class 100,000 | FANUC 發那科 | JPN | Monochrome | 470*470 | 490 |
| 206 | 100 | Horizontal | ALL-ELECTR | Clean room class 100,000 | FANUC 發那科 | JPN | Monochrome | 450*470 | 400 |
| 207 | 100 | Vertical | ALL-ELECTR | Clean room class 100,000 | FANUC 發那科 | JPN | Monochrome, duplex turntable | 500*335 | 450 |
| 208 | 90 | Horizontal | Oil hydraulic | Clean room class 100,000 | CREATOR 群基 | TW | Monochrome | 470*470 | 420 |
| 209 | 40 | Horizontal | Oil hydraulic | Clean room class 100,000 | CREATOR 群基 | TW | Monochrome | 430*430 | 400 |
| 210 | 100 | Horizontal | ALL-ELECTR | Clean room class 100,000 | SUMITOTO 住友 | JPN | Monochrome | 380*380 | 320 |
| 211 | 80 | Horizontal | Oil hydraulic | Clean room class 100,000 | VICTOR
台中精機 | TW | Monochrome | 380*380 | 320 |
| 212 | 100 | Horizontal | ALL-ELECTR | Clean room class 100,000 | SUMITOTO 住友 | JPN | Monochrome | 340*340 | 300 |
| 213 | 45 | Horizontal | Oil hydraulic | Clean room class 100,000 | CREATOR
群基 | TW | Monochrome | 340*340 | 300 |
| Item No. | Machine | Type No. | Manufacturer | Country of manufacturer |
|---|---|---|---|---|
| 1 | CNC discharge motor 1 | S602C | MOLDMASTER 億耀 | TW |
| 2 | CNC discharge motor 2 | S430A | MOLDMASTER 億耀 | TW |
| 3 | CNC discharge motor 3 | S430A | MOLDMASTER 億耀 | TW |
| 4 | 1.8 Milling machine 1 | 5KV | MYTECH 首鑽 | TW |
| 5 | 1.8 Milling machine 2 | V200 | MANFORD 邁鑫 | TW |
| 6 | 1.8 Milling machine 3 | V200 | MANFORD 邁鑫 | TW |
| 7 | Grinding machine | N/A | TATUNG-OKUMA 大同 | TW |
| 8 | CNC Surface Grinding Machine | N/A | SIN GAR 星加 | TW |
| 9 | Lathe | N/A | VICTOR 台中精機 | TW |
| 10 | Drilling machine | KSD-13 | HSIN GEELI 金山 | TW |
| 11 | Cutting machine1 | LY-300 | 理陽 | TW |
| 12 | Cutting machine2 | N/A | 理陽 | TW |
| 13 | Grinding machine | N/A | 辰光 | TW |
| 14 | Grinders | N/A | 良賀 | TW |
| 15 | Height detector | N/A | N/A | TW |
| 16 | Height drawer | N/A | N/A | TW |
| 17 | CNC Milling machine (Vertical Spindle) 1 | 2016-05-15 | LK MACHINERY力勁 | TW |
| Item No. | Department | Floor | Application |
|---|---|---|---|
| 1 | Air conditioning area | First | Automatic drilling machine for OEM products |
| 2 | Clean room class 100,000 | Second | Roller clamp assembly machine for P/N 11C101 |
| 3 | Clean room class 100,000 | Second | NFC assembly machine |
| 4 | Clean room class 100,000 | Second | NFC assembly machine |
| 5 | Clean room class 100,000 | Second | NFC assembly machine |
| 6 | Clean room class 100,000 | Second | NFC assembly machine |
| 7 | Clean room class 100,000 | Second | NFC assembly machine |
| 8 | Clean room class 100,000 | Second | NFC assembly machine |
| 9 | Clean room class 100,000 | Second | NFC assembly machine |
| 10 | Clean room class 100,000 | Second | NFC assembly machine |
| 11 | Clean room class 100,000 | Second | Vial adapter assembly machine |
Annual once calibration of measuring instruments
Base: High-precision granite platform
Measuring stroke (X.Y.Z) Three axes: 300mm * 200mm * 200mm
Stage Size: 505 mm * 355 mm
Carrying weight: 25Kg
Transmission mode:
X. Y. Z axis servo motor
Maximum moving speed:
X. Y. Z-axis 120 mm / sec
Optical ruler:
X. Y. Z-axis, resolution 0.5um
Linear Accuracy:
X. Y. Z-axis, (3 + L / 150) μm
Body: C-type structure
Appearance size:
1070mm * 850mm * 1900mm
Made in TW
